How to Install Your Vittoria Air-Liner Light Gravel Insert
Follow this Vittoria video guide to build a cyclocross tubeless setup using the Terreno Endurance T30 tire and Air-Liner CX insert. Explore the components you need, prepare the wheel and follow the installation demonstration before completing the final tire and pressure checks.
Before you start - Important safety information
Before installation, check compatibility between your gravel tyre, tubeless rim, Air-Liner Light Gravel insert and tubeless valve. Inspect rim tape and follow the current Vittoria product instructions. Respect tyre and rim pressure limits. Sealant quantity and any product-specific instructions require Vittoria technical approval.
Your recipe for the perfect set-up
What You'll Need
Tick off your products and tools as you prepare them.
☐ 1 × Vittoria Air-Liner Light Gravel insert
☐ 1 × compatible tubeless gravel tyre
☐ 1 × compatible tubeless-ready wheel and rim
☐ 1 × Vittoria Multiway tubeless valve
☐ Vittoria Universal Tubeless Sealant
☐ Hand or floor pump
☐ Vittoria Universal Tyre Levers
☐ Suitable insert-removal tool
Gather the Air-Liner Light Gravel insert, compatible tire and wheel, Multiway tubeless valve, sealant and installation tools shown in the video.
Check the rim tape and prepare the Multiway tubeless valve. The demonstration shows the valve being fitted through the rim hole.
Fit the first bead of the gravel tire onto the rim, keeping it positioned correctly as you work around the wheel.
Place the insert inside the tyre and around the rim. Work evenly to keep it correctly positioned without twisting.
Fit the second bead gradually, checking that the insert remains inside the tire and the bead seats in the rim channel.
Check the tire bead position and inflate using the approved procedure and pressure limits for your tire and rim.
Remove the valve core as shown and add Vittoria Universal Tubeless Sealant through the valve. Use only the technically approved quantity.
Reinstall the valve core, reinflate as required and distribute the sealant around the tire. Check seating and air retention before riding.
The second part of the video demonstrates how to remove the Air-Liner Light Gravel insert. Deflate the tire and carefully unseat the tire bead as shown.
Use the removal method demonstrated in the video to lift out the insert, then remove residual sealant and inspect the tire and rim.
